Epson EMP-X5 Service Manual

4-40
EMP-822/EMP-83/EMP-X5/EMP-S5
SEIKO EPSON Revision:A
 Components of the Optical Engine and MAB set
EMP-822/83 EMP-X5/S5
Optical Engine
OPTICAL ENGINE OPTICAL ENGINE
MA Board Assy.
PRINTED CIRCUIT BOARD
ASSEMBLY;MA_R1
PRINTED CIRCUIT BOARD
ASSEMBLY;MA_S2
MA Plate
PLATE,MA PLATE,MA
MA Shield
SHIELD,MA SHIELD,MA
Screw
C.C.SCREW,3X6,F/ZN-3C C.C.SCREW,3X6,F/ZN-3C
IF Board Assy.
PRINTED CIRCUIT BOARD
ASSEMBLY;IF_R1
--

Epson EMP-X5 Specifications

General

Resolution	1024 x 768 (XGA)
Contrast Ratio	400:1
Lamp Life	3000 hours (Normal Mode), 4000 hours (Eco Mode)
Display Technology	3LCD
Zoom Ratio	1.2x
Projection Size	30 - 300 inches
Brightness	2200 lumens
Weight	2.7 kg
Inputs	Composite video, S-Video
Noise Level	35 dB (standard), 28 dB (economy)
