Epson EMP-X5 Service Manual

4-45
EMP-822/EMP-83/EMP-X5/EMP-S5
SEIKO EPSON Revision:A
• Route the cable of the Lamp Fan under the Intake Duct.
Figure 4-43.
 When installing the Inner Exhaust Duct A, check the following.
• The Lamp Connector is secured to the notch of the Inner Exhaust Duct A.
• The Safety Switch is secured to the notch of the Inner Exhaust Duct A.
Figure 4-44.
Intake Duct
Lamp Fan
Lamp Connector
Safety Switch
Inner Exhaust Duct A

Epson EMP-X5 Specifications

General

Resolution	1024 x 768 (XGA)
Contrast Ratio	400:1
Lamp Life	3000 hours (Normal Mode), 4000 hours (Eco Mode)
Display Technology	3LCD
Zoom Ratio	1.2x
Projection Size	30 - 300 inches
Brightness	2200 lumens
Weight	2.7 kg
Inputs	Composite video, S-Video
Noise Level	35 dB (standard), 28 dB (economy)
