Note:
❏ You may need to stop using a Carrier Sheet that is scratched or has been scanned more than 3,000 times.
❏ To scan both sizes and stitch them together, set the appropriate setting in Epson ScanSmart. Click
Settings >
Scanner Settings tab > Scan Settings button > Main Settings tab on the Epson Scan 2 window. Select Double-
Sided as the Scanning Side, and then select Le & Right from Stitch Images.
❏ When scanning a Carrier Sheet by selecting Auto Detect as the Document Size setting on Epson ScanSmart, the
image is automatically scanned by applying Paper Skew in the Correct Document Skew setting.
You can check the setting by clicking
Settings > Scanner Settings tab > Scan Settings button > Main Settings
tab on the Epson Scan 2 window.
❏ e leading edge of the original must be placed at the binding part of the Carrier Sheet when scanning an original
approximately 297 mm long. Otherwise, the length of the scanned image may be longer than intended as the scanner
scans to the end of the Carrier Sheet when you select Auto Detect as the Document Size setting in Epson
ScanSmart.
❏ Only use the Carrier Sheet designed for your scanner. e Carrier Sheet is automatically recognized by the scanner
by detecting two small rectangular holes on the front edge. Keep the holes clean and not covered.
Related Information
& “Scanning Documents from Computer (Epson ScanSmart)” on page 83
Using Epson ScanSmart, you can easily scan and save your documents.
Irregular Shaped Originals
Specications of Irregular Shaped Originals
By using the Carrier Sheet, you can scan originals that are wrinkled, curled, very thin, or irregularly shaped.
Size Thickness Loading Capacity of the Carrier
Sheet
Up to A4 0.3 mm (0.012 in.) or less
(excluding the thickness of the Carrier
Sheet)
10 sheets
User's Guide
Scanning Documents or Other Originals
75
