Assembling the Printer
Slide the print head from side to side to make sure it moves
smoothly. Also check that the ribbon is not twisted or creased.
Replace the paper-tension unit by placing it on the printer’s
mounting pegs and lowering it into place. Press down on both
ends of the unit until you feel it click into place.
Replace the printer cover by first inserting the front tabs into the
slots on the printer and then lowering it into place. Finally, push
it down until it clicks.
1-8
Setting Up the Printer
