Epson GT-30000 User Manual

Solving Problems
117
3. If paper jams in the paper eject
position, open the cover on the right
and slowly pull out the jammed paper
as shown. (Be careful not to pull too
hard or the paper may tear, making it
more difficult to remove.)
4. If the paper tears, open the middle
cover and remove the paper.
Changing the Document Feed Speed
When you scan using the automatic
document feeder, you can select a
document feed speed of
Low
and
High
. Under normal conditions, use
the high speed mode. If you want to
scan thick documents or reduce
noise of an image, use the low speed
mode.
To change the document feed speed,
lift the ADF and locate the switch as
shown. Slide the switch up for high
speed, or down for low speed.
High
Low

Epson GT-30000 Specifications

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without ADF	65W
power consumption operating with ADF	90W
power consumption standby without optional unit	12W

Operating Environment

temperature operating	41ºF to 95ºF (5ºC to 35ºC)
humidity operating	10% to 80% (no condensation)
humidity storage	10% to 85% (no condensation)

Scanning Specifications

optical resolution	600 x 1200 dpi with Micro Step Drive™ technology
maximum resolution	9600 x 9600 dpi with interpolation
effective pixels	7020 x 10200 pixels (600 dpi)
color depth internal	36 bits per pixel
color depth external	24 bits per pixel (selectable)
grayscale depth internal/external	12 bits per pixel
grayscale depth external	8 bits per pixel
scanning speed at 1600 dpi, draft mode, color	0.79 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, grayscale	0.39 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, art	0.39 msec/line (approx.)

Weight and Dimensions

maximum read area	11.7" x 17.0" (297mm x 432mm)
width	25.9" (658mm)
depth	19.2" (488mm)
height	10.0" (254mm)
weight	66 lb (37.5 kg approx.)
