Epson GT-30000 User Manual

90
Network Scanning
8. When you see the Screen Calibration
window, move the slider right or left until
the stripes match as closely as possible.
(The stripes will not match perfectly and
the recommended setting is 1.8.) Then
click
OK
.
The EPSON Screen Calibration Utility
calibrates the preview image you see in
your EPSON TWAIN HS driver to match
your monitor settings.
9. Follow the instructions on the screen to
install EPSON Scan Server. When you see
the window on the right, make sure
GT-30000
is selected under Scanner
Selection.
Select either
Icon
or
Dialogbox
as the
scanner server start up mode. (See
“Changing the Scanner Server Start Up
Mode” on page 91 for details about the
start up mode.)
10. Click
Test
to test scanner operation.
OK. Scanner available
appears under
Status if the scanner is communicating
with the scanner server. Click
OK
to close
the window.
If you want to share a different network scanner with the client
computers, you can access the EPSON Scan Server window at any time
by double-clicking the EPSON Scan Server icon in the Windows Control
Panel. Then select the scanner you want in the Scanner Selection list.
11. Follow the instructions on the screen to complete installation of any other
software you’ve selected in the EPSON Software Setup window. If you’re done
installing software, restart your computer. Refer to “Installing Additional
Software” on page 49 if you want to install the ISIS driver, PixTools QuickScan,
or Presto! PageManager.

Epson GT-30000 Specifications

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without ADF	65W
power consumption operating with ADF	90W
power consumption standby without optional unit	12W

Operating Environment

temperature operating	41ºF to 95ºF (5ºC to 35ºC)
humidity operating	10% to 80% (no condensation)
humidity storage	10% to 85% (no condensation)

Scanning Specifications

optical resolution	600 x 1200 dpi with Micro Step Drive™ technology
maximum resolution	9600 x 9600 dpi with interpolation
effective pixels	7020 x 10200 pixels (600 dpi)
color depth internal	36 bits per pixel
color depth external	24 bits per pixel (selectable)
grayscale depth internal/external	12 bits per pixel
grayscale depth external	8 bits per pixel
scanning speed at 1600 dpi, draft mode, color	0.79 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, grayscale	0.39 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, art	0.39 msec/line (approx.)

Weight and Dimensions

maximum read area	11.7" x 17.0" (297mm x 432mm)
width	25.9" (658mm)
depth	19.2" (488mm)
height	10.0" (254mm)
weight	66 lb (37.5 kg approx.)
