Epson GT-30000 User Manual

Installing the TCP/IP Protocol
127
Assigning an IP Address on Windows NT 4.0
If your network is connected to the Internet, ask your Internet provider or system
administrator for a formal IP address.
If your network is not connected to the Internet, you can use an IP address in the
following ranges: 10.0.0.0 to 10.255.255.255, 172.16.0.0 to 172.31.255.255, or
192.168.0.0 to 192.168.255.255. Make sure you use a different IP address for every
computer on your network. If you are running a mixed Windows 95, Windows 98,
Windows Me, Windows 2000 and Windows NT environment, you can use an IP
address in the range of 169.254.XXX.XXX.
If you use IP addresses in the ranges listed above, you need to change
them before you connect the network to the Internet. Otherwise you’ll
experience IP address conflicts.
If your network uses a DHCP server, you don’t need to obtain an IP
address before beginning this procedure; the server finds one for you.
Follow the steps below to assign the IP address to your computer:
1. Select
TCP/IP Protocol
in the Network Protocols list on the Protocols tab, and
then click the
Properties
button.
2. Click the
IP Address
tab to display the
screen on the right.
3. Click
Specify an IP address
, and then enter
your IP address and subnet mask. Click
OK
.
(If you’re using a DHCP server on your
network, you can assign an IP address
automatically by selecting
Obtain an IP
address from a DHCP server
and
clicking
OK
.)
4. Click
OK
again to close the Network
window and have your IP address assignment
take effect.
Make sure you share the IP address for the
scanner server with all client computers on
the network.

Epson GT-30000 Specifications

Power

voltage	AC 100V-120V, 220V-240V
frequency	50-60Hz
power consumption operating without ADF	65W
power consumption operating with ADF	90W
power consumption standby without optional unit	12W

Operating Environment

temperature operating	41ºF to 95ºF (5ºC to 35ºC)
humidity operating	10% to 80% (no condensation)
humidity storage	10% to 85% (no condensation)

Scanning Specifications

optical resolution	600 x 1200 dpi with Micro Step Drive™ technology
maximum resolution	9600 x 9600 dpi with interpolation
effective pixels	7020 x 10200 pixels (600 dpi)
color depth internal	36 bits per pixel
color depth external	24 bits per pixel (selectable)
grayscale depth internal/external	12 bits per pixel
grayscale depth external	8 bits per pixel
scanning speed at 1600 dpi, draft mode, color	0.79 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, grayscale	0.39 msec/line (approx.)
scanning speed at 1600 dpi, draft mode, art	0.39 msec/line (approx.)

Weight and Dimensions

maximum read area	11.7" x 17.0" (297mm x 432mm)
width	25.9" (658mm)
depth	19.2" (488mm)
height	10.0" (254mm)
weight	66 lb (37.5 kg approx.)
