Epson L5190 Series User Manual

5. Examine the printed pattern.
❏ If you cannot see any broken lines or missing segments as in the following "OK" pattern, the nozzles are not
clogged. Select No to close the nozzle check feature. No further steps are necessary.
❏ If there are broken lines or missing segments as shown in the "NG" pattern, the print head nozzles may be
clogged. Go to the next step.
6. Select Ye s , and then follow the on-screen instructions to clean the print head.
7. When cleaning is nished, print the nozzle check pattern again. Repeat cleaning and printing the pattern until
all lines are printed completely.
Related Information
& “Loading Paper in the Rear Paper Feed” on page 49
Checking and Cleaning the Print Head - Windows
1.
Load A4-size plain paper in the printer.
2. Access the printer driver window.
3. Click Nozzle Check on the Maintenance tab.
4. Follow the on-screen instructions.
Related Information
& “Loading Paper in the Rear Paper Feed” on page 49
& “Accessing the Printer Driver” on page 80
Checking and Cleaning the Print Head - Mac OS
1. Load A4-size plain paper in the printer.
2. Select System Preferences from the
menu > Printers & Scanners (or Print & Scan, Print & Fax), and
then select the printer.
3. Click Options & Supplies > Utility > Open Printer Utility.
4.
Click Nozzle Check.
User's Guide
Maintaining the Printer
148

Epson L5190 Series Specifications

General

Print Technology	Inkjet
Print Resolution	5760 x 1440 DPI
Scanner Type	Flatbed color image scanner
Ink Type	Dye Ink
ADF Capacity	30 sheets
Copy Function	Yes
Fax Function	Yes
Scan Resolution	1200 x 2400 DPI
Duplex Printing	Manual
Connectivity	USB, Wi-Fi, Wi-Fi Direct
Paper Sizes	A4, A5, A6, B5, Letter, Legal
Functions	Print, Scan, Copy
Print Speed (Color)	5 pages/min
Paper Handling Input	100 sheets
Ink Bottles	Black, Cyan, Magenta, Yellow
Ink Tank Capacity (Color)	70 ml
Mobile Printing	Epson iPrint, Google Cloud Print
Display	1.44" LCD screen
Dimensions (W x D x H)	375 x 347 x 237 mm
Printer Type	All-in-One
