6. Insert the ribbon cartridge into the printer as shown; then
press both sides of the cartridge firmly to fit the plastic hooks
into the printer slots.
7. Turn the ribbon-tightening knob to help feed the ribbon into
place; it should not be twisted or creased.
8. Replace the paper tension unit and printer cover.
After you install the color ribbon cartridge, run the self test as
described on “Running the Self Test” on page 1-11.

Epson LX-300+ Specifications

General

Emulation	Epson ESC/P, IBM PPDS
Print Method	9-pin, impact dot matrix
Interface	Parallel
Paper Handling	Friction feed
Dimensions	366 x 275 x 159 mm
Paper Width	4 - 10 inches
