If the top or bottom edge of the characters in the self test are a
different color from the rest, adjust the ribbon angle. Check the
characters printed in red. If the top edge is blue, move the color
ribbon adjustment lever forwards. If the bottom edge is yellow,
move the lever backwards. Then print another self test to check
your adjustment. Repeat this process until the ribbon is properly
adjusted.
Note:
When you print using the color ribbon, the print speed is reduced.
To switch to the black ribbon, remove the color ribbon as shown
in the manual that comes with the color upgrade kit; then install
the black ribbon as described on “Installing the ribbon cartridge”
on page 1-7.
You do not have to remove the motor unit.
