Maintenance 4. Joint #1 (Replacing the Motor)
S5 Rev.5 99
(8)
Remove
the Joint #1 motor plate from the Joint #1
motor.
(
9)
Remove
caked-on liquid gasket residue with
a
scraper or similar tool.
