Maintenance 9. Cable Unit
168 S5 Rev.5
Double
-check the bolts to make sure that you have not forgotten to tighten any of
them.
Cable
Unit
Installation
(1)
Pass the lead line (with the connector plate attached) through the back of the Base
and
Arm #1 to Arm #4.
(2)
Connect the J
oint #1 motor connector to the lead line.
Remove the backup battery.
(3)
Press the
lead line into the Base and mount the Connector
Plate.
Hexagon socket button head bolt : 8-M4×10
Tightening torque : 1.4 N·m (0.14 kgf·m)
Be
careful not to catch the cables between the Base and
the Connector Plate.
(4)
Put the lead line
around the Arm #3 as shown in the
picture.
(5)
Pass a wire tie through the supporting plate.

NOTE

NOTE
