2. Installation
RC700 / RC90 Option Fieldbus I/O Rev.14 207
Address
Signal Name
Controller Bit No
RX(n+1)8
ErrorCode512
*1
536
RX(n+1)9
ErrorCode1024
*1
537
RX(n+1)A
ErrorCode2048
*1
538
RX(n+1)B
ErrorCode4096
*1
539
RX(n+1)C
ErrorCode8192
*1
540
RX(n+1)D
CmdRunning
*1
541
RX(n+1)E
CmdError
*1
542
RX(n+1)F
NA
543
RX(n+2)0
NA
544
:
:
RX(n+4)F
NA
591
RX(n+5)0
NA
592
RX(n+5)1
NA
593
RX(n+5)2
NA
594
RX(n+5)3
NA
595
RX(n+5)4
NA
596
RX(n+5)5
NA
597
RX(n+5)6
NA
598
RX(n+5)7
NA
599
RX(n+5)8
NA
600
RX(n+5)9
NA
601
RX(n+5)A
NA
602
RX(n+5)B
Remote Ready
*2
603
RX(n+5)C
NA
604
RX(n+5)D
NA
605
RX(n+5)E
NA
606
RX(n+5)F
NA
607
*1: Remote control inputs and outputs are not allocated to fieldbus slave I/O by default.
To allot remote control input and output to fieldbus slave I/O, refer to 3.5 Setting
Remote Control Input and Output later in this manual.
*2 When initialization of the CC-Link board is completed at the Controller turn-on,
Remote Ready flag [RX(n+5)B] turns ON.
I/O assignment of Remote Ready cannot be changed or disabled (NA).
