2. Installation
152 RC700 / RC90 Option Fieldbus I/O Rev.14
2.3.4 Installing EtherNet/IP Board manufactured by Hilscher
Appearance
Rotary Switch
Status display LED (×3)
Ethernet Interface (Channel 0)
Ethernet Interface (Channel 1)
