2. Installation
RC700 / RC90 Option Fieldbus I/O Rev.14 37
17-a Select [Connection Configuration] tab. Connections Parameters appear
to communicate with the slave device.
- Displayed items are different depending on the slave device.
- Displayed Connections Parameters are information that is set on the
Fieldbus master board. Confirm that the information matches with
that of the slave device.
Change parameters as necessary.
After completing setting, click <OK>.
Connections Parameters that are set for the Fieldbus master board and
information of the slave device need to be matched.
Communication with the slave device is not performed if they do not
match. Change the information of either Connections Parameters or
Fieldbus master board.
Please consult with the slave device manufacturer if the information is
unclear.
