2. Installation
74 RC700 / RC90 Option Fieldbus I/O Rev.14
DeviceNet Communication Specifications
Item
Specification
Name
DeviceNet slave board
Supported Connection I/O messaging connection (Polling), Explicit message
connection
DeviceNet communication protocol
Baud Rates
125 k / 250 k / 500 k (bps)
Transfer Distance
Baud Rates
Max.
Network
Length
Drop Length
Total Drop Line
Length
500 k (bps)
100 m
6 m or under
39 m or under
250 k (bps)
250 m *
6 m or under
78 m or under
125 k (bps)
500 m *
6 m or under
156 m or under
Cable 5-wire cable dedicated to DeviceNet
(2 wires for signal, 2 wires for power supply, 1 shield wire)
Communications
Power Supply Voltage
24 VDC (supplied from a connector)
Communication
Power Supply Current
Consumption
Maximum 30 mA
Mode
Slave
Interface
1 DeviceNet port
Max. Input data size
2048 bits (256 bytes)
Max. Output data size
2048 bits (256 bytes)
* When Thin cable is used for trunk line, the maximum network length is 100 m.
LED Description
LED state represents the status of the fieldbus board.
LED state
NS
MS
OFF
Communications power supply OFF
Disconnected
Device power supply OFF
GRN
ON
Link OK
Online connected
Device operating
Blinking
Online disconnected
Data size error
RED
ON
Link error
Critical error
Blinking
Communication time out
Error
