SC-F9200 Series
Revision B
DISASSEMBLY & ASSEMBLY
Disassembl
y and Assembly Procedure
112
SE Group Confidential (Related St
aff Only)
8.
Holding the Front Cover
upright, remove the Left Upper Co
ver pulling out it
s joint
part in the direction of the arrow.
Figure 3-32. Removing
the Lef
t Upper Cover
Left Upper Cover
Front Cove
r
Joint part
111
