Epson SC-F9200 series Service Manual

SC-F9200 Series Revision B
MAINTENANCE Cleaning 377
SE Group Confidential (Related Staff Only)
7. Wipe off the media holding plates using a soft cloth that has been soaked in water.
Figure 5-4. Cleaning the media holding plates
8. Close the front cover.
HEAT SHIELD
1. Use your fingers to completely remove the five screws securing the heat shield,
and remove the heat shield.
Figure 5-5. Cleaning the Heat Shield (1)
C H E C K
P O I N T
 Normally, wipe off any lint and dust that has attached to the
surface, without removing the media holding plates.
 When media with glue is used or ink has adhered to the surface
of the media holding plates, remove the plates, and wipe stains
off both the front and rear surfaces.
