Epson SC-F9200 series

SC-F9200 Series Revision B
MAINTENANCE Cleaning 381
SE Group Confidential (Related Staff Only)
3. Clean the front and back of the wiper with a cleaning stick.
Figure 5-13. Cleaning the Wiper (1)
4. Clean the bottom of the wiper with a cleaning stick.
Figure 5-14. Cleaning the Wiper (2)
5. Clean the attachment points with a cleaning stick.
Figure 5-15. Cleaning the Wiper (3)
C H E C K
P O I N T
If the wiper part has split off or is broken, we recommend replacing
it with a new one.
