Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
TROUBLE SHOOTING Remedies for Service Call Error 48
SE Group Confidential (Related Staff Only)
141A
Pump Motor
overload error
Overcurrent to the Pump Motor was detected.
 Pump Motor encoder cable disconnection
 Pump Motor cable disconnection
 Irregular load
 Pump Motor encoder failure
 Pump Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 Pump Motor (Pump Motor encoder) to Main
Board (CN210/CN230)
2. Does the Pump Motor encoder work properly?
Check it using the Service Program.
Replace the Pump Motor encoder and Pump Motor
(Pump Cap Unit 2).
(Page 177)
141B
Pump Motor
over speed error
The Pump Motor was driven at a speed faster than a
predetermined one during deceleration.
 Irregular load
 Pump Motor encoder failure
 Pump Motor driver failure
Does the Pump Motor encoder work properly? Check
it using the Service Program.
1. Replace the Pump Motor encoder (Pump Cap
Unit2). (Page 177)
2. Replace the Main Board. (Page 123)
141C
Pump Motor
reversing error
The number of occurrences of reversing the Pump
Motor has reached a predetermined limit.
 The polarity of Pump Motor encoder cable is
opposite.
 The polarity of Pump Motor cable is opposite.
1. Is there any problems such as damaged cable in the
connections below?
 Pump Motor (Pump Motor encoder) to Main
Board (CN210/CN230)
2. Does the Pump Motor encoder work properly?
Check it using the Service Program.
Replace the Pump Motor encoder (Pump Cap Unit
2). (Page 177)
141D
Pump Motor
driving time-out error
Abnormally-long driving duration of the Pump Motor
was detected.
 Irregular load
 Firmware becomes out of control.
---
Replace the Main Board. (Page 123)
Table 2-4. Troubleshooting for Service Call Error
Code Error Name Cause Check Item Remedy
