Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
TROUBLE SHOOTING Trouble on Paper Feeding 69
SE Group Confidential (Related Staff Only)
Actual margins differ from the specified
margins.
Paper feed amount is not configured
correctly.
---
Perform the Feed Adjustment.
(Page 341)
The Media Size Check function has
been disabled.
---
Enable (select “ON”) the Media Size Check
function. (The printer is not capable of precisely
correcting less than 2 mm differences.)
The Media End Check function has
been disabled.
---
Enable (select “ON”) the Media End Check
function.
The Tension Check function has been
set to OFF.
---
Set the Tension Check function to other than OFF.
The end of Roll paper is not detected and
paper falls.
Roll paper whose end edge is secured to
the core was used with the Tension
Check function set to OFF.
---
Make either one or both of the following settings.
 Set the Tension Check function to other than
OFF.
 Enable (select “ON”) the Media End Check
function.
The Tension Check function has been
set to OFF with the Media End Check
function disabled.
---
Make either one or both of the following settings.
 Set the Tension Check function to other than
OFF.
 Enable (select “ON”) the Media End Check
function.
Roll paper is reeled off at a slant, or the
reeled-off paper gets wrinkled.
The Media Guide Bar is not parallel.
---
Perform the Parallel adjustment of the Auto Take-
up Reel Unit referring the User’s guide.
Roll paper is reeled off at a slant, or the
reeled-off paper gets wrinkled.
The tensioner has become distorted for
some reason. (It can be distorted if
excessive force is applied.)
---
Replace the Reel Unit.
(Page 245)
“Media Set Error” occurs. PW Sensor is contaminated. Is the PW Sensor contaminated? Clean the PW Sensor. (Page 375)
“Take-up Error” occurs even though Media
is set to Reel normally.
The Gear at Mounting Plate Assy is
broken.
Is the Gear at Mounting Plate Assy broken? Replace the Mounting Plate Assy.
Table 2-6. Trouble on Paper Feeding
Symptom Cause Check Item Remedy
