Epson SC-S60600 Series User Manual

M
Tighten the screw until the screw no longer turns.
c
Important:
❏ If the roll holder screw is loose, the roll
holder may move during printing. This
could cause stripes and unevenness in
the print results.
❏ If the right and left edges of the roll are
not aligned, realign them.
N
Rotate the handle until part A in the illustration
below is fully inserted.
c
Important:
Once part A is hidden, do not turn the
handle any further. Failure to observe this
precaution could damage the roll holder.
If part A is still visible even after the handle
has been turned fully, rewind the handle.
Loosen the roll holder screw on the right side,
and then restart from Step 4.
O
Insert the media approximately 30 cm into the
opening, then lower the media loading lever.
P
SC-S80600 Series/SC-S60600 Series/SC-S40600 Series User's Guide
Basic Operations
29
