EPSON Stylus CX3100/3200 Revision A
Disassembly and Assembly Overview 37
4.1.4 Service Dispatch Standard
When this machine is completely repaired and returned to the user, confirm finally
according to Check Points in the right list.
Table 4-3. Check List
Classification Part Check item Check column
Printer unit Self test Operation is normal? OK / NG
On line test Print is normally done? OK / NG
Print head (nozzle
check pattern print)
Ink gets out normally from all the
nozzles?
OK / NG
CR mechanism CR smoothly operates? OK / NG
CR makes abnormal sound during
its operation?
OK / NG
Paper loading
mechanism
Paper is smoothly loaded? OK / NG
Paper jam does not happen? OK / NG
Paper does not warp during paper
loading?
OK / NG
Multiple papers are not fed? OK / NG
Abnormal sound is not heard during
paper loading?
OK / NG
There is no alien substance at paper
route?
OK / NG
Scanner unit Mechanism Glass surface is not dirty? OK / NG
Alien substance is not mixed in the
CR movement area?
OK / NG
CR mechanism CR smoothly operates? OK / NG
CR operates together with scanner
unit?
OK / NG
CR makes abnormal sound during
its operation?
OK / NG
Lamp Lamp normally turns on and white
reflection test is done near home
position?
OK / NG
On line test On line test Operation is normal? OK / NG
Copy Copy Local copy is normal? OK / NG
Adjustment Designated
adjustment items
Adjustment condition is suitable?
OK / NG
Lubrication Designated
lubrication items
Lubrication is done at designated
place?
OK / NG
Lubrication volume is suitable? OK / NG
Function Version of
firmware
The newest version
OK / NG
Dispatch
packing
Ink cartridge Ink cartridge is normally installed? OK / NG
Waste ink porous
pad
Remained life of waste ink porous
pad is sufficient?
OK / NG
Protection during
distribution
Printer CR is in the cap position? OK / NG
Scanner CR is locked? OK / NG
Others Attached goods All of attached goods from users are
packed?
OK / NG
Table 4-3. Check List (continued)
Classification Part Check item Check column
