EPSON Stylus CX3100/3200 Revision A
Appendix Electric Circuit Diagrams 83
7.3 Electric Circuit Diagrams
This section shows electric circuit diagrams of Stylus CX3100/3200. The electric
circuits of Stylus CX3100/3200 are provided on the following circuit boards:
C497MAIN Board
Printer circuit
B110MAIN Board
Scanner circuit
C497PSB Board
Power supply circuit
