Epson SureColor F2100 Series User Manual

93
6. Set the height adjustment lever to the P position if you are using a platen or the 1 position if you are
using a grip pad.
7. Press the maintenance button on the control panel.
The Maintenance menu appears.
8. Press the right arrow button to select Nozzle Check.
9. Press the OK button twice.
The nozzle check pattern prints onto the paper.
10. Remove the paper and check the printed pattern:
• If there are no gaps in the pattern, the nozzles are clean.

Epson SureColor F2100 Series Specifications

General

Maximum Print Resolution	1440 x 1440 dpi
Operating System Compatibility	Windows, macOS
Ink Colors	Cyan, Magenta, Yellow, Black, White
Print Technology	PrecisionCore TFP Print Head
Connectivity	USB 2.0, Ethernet
Printer Type	Direct-to-Garment Printer
Ink Configuration	5-color (CMYK + White)
Printable Area	16" x 20"
Media Width	Up to 16 inches
Dimensions (W x D x H)	39" x 49" x 19"
