Epson TM-P80 Technical Reference Guide

104
Specification
• IEEE802.11a/b/g/n (2.4 GHz band or 5 GHz band) compliant wireless LAN communication
compatible
•Infrastructure mode and 802.11 Ad-hoc mode are supported
•Support the IP address automatic acquisition function (DHCP, APIPA).
Communication speed
• IEEE802.11a (5 GHz): Automatic change
• IEEE802.11b (2.4 GHz): Automatic change
• IEEE802.11g (2.4 GHz): Automatic change
• IEEE802.11n (2.4 GHz): Automatic change (65 Mbps at maximum)
• IEEE802.11n (5 GHz): Automatic change (65 Mbps at maximum)
Security
Security can be selected from among the following:
• none
•WEP-64bit (40bit)
•WEP-128bit (104bit)
• WPA-PSK(TKIP)
• WPA-PSK(AES)
*
•WPA-Enterprise (TKIP)
•WPA-Enterprise (AES)
*
* WPA and WPA2 are both supported.
Initial settings
* You can connect to a WPA2-PSK (AES) access point using the settings above.
Parameter Setting value
Communication standard 802.11b/g/n
Network mode Infrastructure mode
SSID EpsonNet
Encryption type WPA-PSK(AES)
Passphrase EpsonNet
IP Address 192.168.192.168
Subnet mask 255.255.255.0

Epson TM-P80 Specifications

General

Type	POS printer
Print technology	Thermal
Dimensions (WxDxH)	110 x 140 x 64 mm
Product color	Black
Safety	UL, CSA
Country of origin	China
Sound pressure level (printing)	53 dB
Supported paper width	79.5 mm
Bluetooth	Yes
USB connector	Mini-USB Type-B
USB 2.0 ports quantity	1
Connectivity technology	Wired
Battery life (max)	46 h
Package depth	230 mm
Package width	185 mm
Package height	103 mm
Package weight	956 g
Cables included	USB
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	-
Ethernet LAN	No
Pallet width	800 mm
Pallet height	768 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	324 pc(s)
Quantity per pallet layer	36 pc(s)
Quantity per pallet layer (UK)	54 pc(s)
