Epson TM-P80 Technical Reference Guide

Appendix
105
Printing communication protocol
•LP, LPR: Transfers printing data
•TCP Socket Port:Transfers printing data and printer status via bidirectional direct socket
communication.
LP, LPR
Socket communication
Notes on Wireless LAN connection
Because not all the combinations of the printer and wireless LAN devices have been checked for
operation, the operation of the printer in combination with all the wireless LAN devices is not
guaranteed. Especially in the ad-hoc mode, the printer may not operate normally, depending on
the combination of t
he device to connect with. Be sure to carry out evaluation of the operation
before use.
•Max. simultaneous connections: 2
•Number of connections for which printing is
available:
1 (Other users need to wait until printing
is completed.)
•Time out:1 min. (changeable)
•Job cancel: Not avai
lable
•Banner printing:Not available
•Port type TCP communication port for direct
printing
•Port number 9100
•Port communication direction bidirectional
•Max. simultaneous connections2
•Number of connections for which printing is
available
1 (Other users need to wa
it until printing
is completed.)
•Time out:1 min. (changeable)

Epson TM-P80 Specifications

General

Type	POS printer
Print technology	Thermal
Dimensions (WxDxH)	110 x 140 x 64 mm
Product color	Black
Safety	UL, CSA
Country of origin	China
Sound pressure level (printing)	53 dB
Supported paper width	79.5 mm
Bluetooth	Yes
USB connector	Mini-USB Type-B
USB 2.0 ports quantity	1
Connectivity technology	Wired
Battery life (max)	46 h
Package depth	230 mm
Package width	185 mm
Package height	103 mm
Package weight	956 g
Cables included	USB
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	-
Ethernet LAN	No
Pallet width	800 mm
Pallet height	768 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	324 pc(s)
Quantity per pallet layer	36 pc(s)
Quantity per pallet layer (UK)	54 pc(s)
