Epson TM-P80 Technical Reference Guide

Chapter 3 Application Development Information
73
3
NV Graphics Print Mode
You can confirm the following information by running NV graphics print mode:
Starting the NV graphics print mode
Follow the steps below to run this mode.
1
Install the roll paper.
2
Close the roll paper cover.
3
While pressing the Feed button, turn on the printer. (Keep pressing the
button until the printer starts printing.)
The printer starts printing the current status of the printer.
When the printer finishes printing the printer status, the following message is printed and
the POWER LED flashes. (The printer is now in the self-test wait mode.):
“Select Modes by pressing Feed button.
Continue SELF-TEST: Less than 1 second
Mode Selection : 1 second or more”
4
Press the Feed button. (Keep pressing the button until the printer starts
printing.)
The printer starts printing instructions.
5
After the printing has been completed, press the Feed button.
6
Press the Feed button again. (Keep pressing the button until the printer
starts printing.)
The printer starts printing the NV graphics information.
Turn the power off and on to return to the normal mode.
 Capacity of the NV graphics  Used amount of the NV graphics
 Unused capacity of the NV graphics  Number of NV graphics that are registered
 Key code, number of dots in X direction, number
of dots in Y direction
 NV graphics data
For detailed information about NV graphics, see "NV Graphics Memory" on page 27.

Epson TM-P80 Specifications

General

Type	POS printer
Print technology	Thermal
Dimensions (WxDxH)	110 x 140 x 64 mm
Product color	Black
Safety	UL, CSA
Country of origin	China
Sound pressure level (printing)	53 dB
Supported paper width	79.5 mm
Bluetooth	Yes
USB connector	Mini-USB Type-B
USB 2.0 ports quantity	1
Connectivity technology	Wired
Battery life (max)	46 h
Package depth	230 mm
Package width	185 mm
Package height	103 mm
Package weight	956 g
Cables included	USB
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	-
Ethernet LAN	No
Pallet width	800 mm
Pallet height	768 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	324 pc(s)
Quantity per pallet layer	36 pc(s)
Quantity per pallet layer (UK)	54 pc(s)
