Epson TM-P80 Technical Reference Guide

30
Installing the Printer
You can install the printer horizontally or vertically. You can also carry it using the belt clip on
the back of the printer to hang the printer on your belt.
Notes on Using the Wi-Fi Models
•Keep the printer away from the devices, such as kitchen microwaves, that may cause radio
wave interference.
•Use channels that are away from the frequency bands that may cause radio wave interference.
•Place shields between the printer and the devices that may cause radio wave interference.
•Select either 2.4 GHz or 5 GHz, whichever is free from radio wave interference.
•In auto channel setting for the access point, do not select a channel in which the printer may
cause radio wave interference.
 When you install the printer vertically, only the orientation shown below is available. Do
not install the printer upside down.
 When you install the printer horizontally, it is recommended to remove the belt clip.
Remove the two screws fixing the clip to remove it.

Epson TM-P80 Specifications

General

Type	POS printer
Print technology	Thermal
Dimensions (WxDxH)	110 x 140 x 64 mm
Product color	Black
Safety	UL, CSA
Country of origin	China
Sound pressure level (printing)	53 dB
Supported paper width	79.5 mm
Bluetooth	Yes
USB connector	Mini-USB Type-B
USB 2.0 ports quantity	1
Connectivity technology	Wired
Battery life (max)	46 h
Package depth	230 mm
Package width	185 mm
Package height	103 mm
Package weight	956 g
Cables included	USB
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	-
Ethernet LAN	No
Pallet width	800 mm
Pallet height	768 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	324 pc(s)
Quantity per pallet layer	36 pc(s)
Quantity per pallet layer (UK)	54 pc(s)
