Epson TM-P80 Technical Reference Guide

Chapter 2 Setup
41
2
6
Configure the [Network] settings and the [TCP/IP] settings.
7
Disconnect the USB cable, turn off the printer, and then turn it back on.
Confirming the operation
Confirm that the printer is connecting to the network. There are the following methods:
•Confirm using a web browser
•Confirm using EpsonNet Config
•Confirm using the PING command from the command prompt
This section describes how to confirm using a web browser.
1
Confirm that the network is running; then start up the computer of the
network.
2
Start up the web browser and input the printer’s IP address in the address
bar.
http://(printer’s IP address)/
3
The “EpsonNet Config” window is displayed.
If the “EpsonNet Config” window is not displayed, connect the computer for setting to the
printer with the USB cable, then confirm the setting again.
To start wireless LAN communication, be sure to disconnect the USB cable, turn off the
printer, and then turn it back on.
If you need to configure other settings, use EpsonNet Config (web version). For information
about EpsonNet Config (web version), see "Starting EpsonNet Config (Web Version)" on
page 65.

Epson TM-P80 Specifications

General

Type	POS printer
Print technology	Thermal
Dimensions (WxDxH)	110 x 140 x 64 mm
Product color	Black
Safety	UL, CSA
Country of origin	China
Sound pressure level (printing)	53 dB
Supported paper width	79.5 mm
Bluetooth	Yes
USB connector	Mini-USB Type-B
USB 2.0 ports quantity	1
Connectivity technology	Wired
Battery life (max)	46 h
Package depth	230 mm
Package width	185 mm
Package height	103 mm
Package weight	956 g
Cables included	USB
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	-
Ethernet LAN	No
Pallet width	800 mm
Pallet height	768 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	216 pc(s)
Quantity per pallet (UK)	324 pc(s)
Quantity per pallet layer	36 pc(s)
Quantity per pallet layer (UK)	54 pc(s)
