Epson TM-T70II Technical Reference Guide

110
NC: Not Connected
ND: Not Defined
28 GND GND GND
29 GND GND GND
30 GND GND GND
31 Host Init
Init Init
32 Printer Fault DataAvail/Data0,4 DataAvail
33 GND ND ND
34 Printer DK_STATUS ND ND
35 Printer +5 V ND ND
36 Host SelectIn
1284-Active 1284-Active
 A signal name with a rule above it indicates an “L” active signal.
 Bidirectional communications cannot take place, unless all signal names for both sides
correspond to each other.
 Connect all signal lines using a twisted-pair cable. Connect the return side to the signal
ground level.
 Make sure the signals satisfy electrical characteristics.
 Set the leading edge and trailing edge times to 0.5 s or less.
 Do not ignore Ack
or BUSY signals during a data transfer. Ignoring such signals may
result in data corruption.
 Make the interface cables as short as possible.
Pin Source
Compatibility
Mode
Nibble Mode Byte Mode

Epson TM-T70II Specifications

General

Type	POS printer
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Maximum printing width	79.5 mm
USB port	Yes
USB connector	USB Type-B
Standard interfaces	Serial, USB 2.0
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Safety	EN, TÜV, GOST-R
Certification	CE, GOST-R, EN55022
Country of origin	China
Autocutter durability	1.7 million cuts
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
AC input voltage	24 V
Power consumption	2000 mA
Power source type	AC
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Mean cycles between failures (MCBF)	65000000
Pallet width	800 mm
Pallet height	1816 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	24 pc(s)
Package depth	253 mm
Package width	192 mm
Package height	240 mm
Package weight	2600 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	194 mm
Width	125 mm
Height	114 mm
