Chapter 1 Product Overview
39
1
Option Specifications
AC Adapter (PS-180)
Material
No specific brominated flame retardants, such as PBBE and PBB, are used in this product.
AC cable selection
Select an AC cable that satisfies the following conditions.
•Safety standard product
•Plug with PE terminal
Ground connections
Be sure to ground for safety.
Electric
characteristics
Input conditions input voltage (rating): AC 90 to 264 V
(AC 100 V -10% to AC 230 V +15%)
Frequency (rating): 50/60 Hz ± 3 Hz
Power consumption (rating): 100 VA
Output conditions Output voltage (rating): DC 24 V ± 5%
Output current (rating): 2.0 A
Output electric power (rating): 48 VA
Output peak current: 4.5 A
Case specifications Dimensions
(H × W × D)
68 × 136 × 32 mm {2.68 × 5.35 × 1.26"}
(excluding projections)
Weight Approx. 0.4 kg {14.11 oz} (excluding the AC cable)
Color Black (matte)
To Next Page
