Epson TM-T70II Technical Reference Guide

Chapter 2 Setup
55
2
dpi: dots per inch
*1: Enabled only for the parallel interface
*2: Enabled only for South Asia font models
*3: Enabled only for ANK models
*4: Excluding some functions.
Functions
Receive buffer capacity
•4 KB (initial setting)
•45 bytes
BUSY condition
•Receive buffer full/Offline (initial setting)
•Receive buffer full
Receipt
Enhancement
Auto top logo ✔*
4
✔
Auto bottom logo ✔✔
Auto top/bottom logo extended functions ✔*
4
✔
 For information about the TM-T70II Utility, see the TM-T70II Utility User’s Manual.
 For information about how to use the memory switch setting mode, see "Memory Switch
Setting Mode" on page 87.
 For information about ESC/POS commands, see the ESC/POS Command Reference.
 In either case above, the printer enters the BUSY state after power is turned on, and
when a self-test is being run.
 If BUSY condition is set to “Receive buffer full,” the printer will not become BUSY
 When the cover is open
 When paper is fed by the Feed button
 When printing has stopped for a paper out
 When macro execution ready state
 When error has occurred
Item\Method
TM-T70II
Utility
Memory
Switch
Setting Mode
ESC/POS
Commands

Epson TM-T70II Specifications

General

Type	POS printer
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Maximum printing width	79.5 mm
USB port	Yes
USB connector	USB Type-B
Standard interfaces	Serial, USB 2.0
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Safety	EN, TÜV, GOST-R
Certification	CE, GOST-R, EN55022
Country of origin	China
Autocutter durability	1.7 million cuts
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
AC input voltage	24 V
Power consumption	2000 mA
Power source type	AC
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Mean cycles between failures (MCBF)	65000000
Pallet width	800 mm
Pallet height	1816 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	24 pc(s)
Package depth	253 mm
Package width	192 mm
Package height	240 mm
Package weight	2600 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	194 mm
Width	125 mm
Height	114 mm
