Epson TM-T70II - Page 33

Chapter 1 Product Overview
33
1
58 mm paper width printing
In 2-divided energizing, the print position within the printable area of the thermal elements
for dots 1 to 208 and 209 to 416 is shifted approximately 0.06 mm {0.0024"} as shown in the
figure below in the paper feed direction.
(2.75 mm)
(2.75 mm)
52 0.2 mm
0.125 0.05 mm
57.5 0.5 mm
2081
209
416
Approx.0.06 mm
