Epson TM-T70II Technical Reference Guide

Chapter 2 Setup
57
2
Depending on the paper type, it is recommended to set the print density as shown in the table
below for the best print quality.
Multi-tone print density
Selectable from levels 1 to 13 (70%  130%)
Initial setting for ANK models: level 7 (100%)
Initial setting for Simplified Chinese models, Traditional Chinese models, and South Asia font
models: level 11 (120%)
Print speed
Selectable from levels 1 to 13 (Slow  Fast)
Initial setting: level 13
Thai character print mode (only for South Asia font models)
•Thai 3 pass
•Thai 1 pass (initial setting)
Selecting the number of head energizing parts
•One-part energizing (initial setting)
•Two-part energizing
Original Paper type Density Level
TF50KS-E, P220AGB-1, AF50KS-E Level 5 (90%)
TF60KS-E, PD160R, PD190R, KT48F20, KT55F20,
F5041
Level 7 (100%)
P300, P310, P350 Level 8 (105%)
When the print density level is increased, printing speed may be reduced.
 First change the print density, and then configure the Multi-tone print density.
 If you set the density too high, the contrast becomes lower. Select the density level
checking the overall tone balance of your image.
Depending on print conditions, such as print duty, print head temperature, and data
transmission speed, print speed is automatically adjusted, which may cause white lines due
to intermittent print (the motor sometimes stops). To avoid this, keep the print speed
constant by setting it lower, or set the transmission speed higher for the serial interface.

Epson TM-T70II Specifications

General

Type	POS printer
Print technology	Thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Maximum printing width	79.5 mm
USB port	Yes
USB connector	USB Type-B
Standard interfaces	Serial, USB 2.0
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Safety	EN, TÜV, GOST-R
Certification	CE, GOST-R, EN55022
Country of origin	China
Autocutter durability	1.7 million cuts
Sound pressure level (printing)	55 dB
Mean time between failures (MTBF)	360000 h
AC input voltage	24 V
Power consumption	2000 mA
Power source type	AC
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Ethernet LAN	No
Mean cycles between failures (MCBF)	65000000
Pallet width	800 mm
Pallet height	1816 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	112 pc(s)
Quantity per pallet (UK)	168 pc(s)
Quantity per pallet layer	16 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	24 pc(s)
Package depth	253 mm
Package width	192 mm
Package height	240 mm
Package weight	2600 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	194 mm
Width	125 mm
Height	114 mm
