Epson WF-7820 Series User Manual

21
Icons Description
Displays the network connection status; select the icon to set up or change your network
connection.
• The product is not connected to a wired (Ethernet) network.
• The product is connected to a wired (Ethernet) network.
• The product is not connected to a wireless network.
• The product is searching for an SSID or experiencing a wireless network
connection issue.
• The product is connected to a wireless network; the number of bars indicates the
connection's signal strength.
• Wi-Fi Direct is not enabled.
• Wi-Fi Direct is enabled.
The Quiet Mode setting is enabled or disabled. Select the icon to change the setting.
Depending on the selected paper type and print quality, when this feature is enabled noise
is reduced during printing, but print speed may also be reduced.
Press this icon to enable sleep mode and turn off the LCD screen.
Indicates that the user restriction feature is enabled. You need to select a user name and
then enter a password. Contact your printer administrator for login information. When
enabled, a user with access permission has logged in. Select the icon to logout.
Displays the Fax Data Information screen.
The indicated setting has changed.
There is a problem with the indicated setting. Press the icon to resolve the problem.
Parent topic: Control Panel Buttons and Lights

Epson WF-7820 Series Specifications

General

Print Resolution	4800 x 2400 dpi
Max Print Size	13" x 19"
Duplex Printing	Yes
Scan Resolution	1200 x 2400 dpi
Paper Capacity	250 sheets
ADF Capacity	50 sheets
Display	4.3" color touchscreen
Functions	Print, Copy, Scan, Fax
Scanner Type	Flatbed colour image scanner
Connectivity	Wi-Fi, Ethernet, Wi-Fi Direct, USB
Mobile Printing	Epson Connect, Apple AirPrint, Google Cloud Print
Paper Sizes	A3, A4, A5, A6, B4, B5, C6, DL
Fax Transmission Speed	Approx. 3 seconds per page
Fax Memory	Up to 550 pages
Print Technology	PrecisionCore
Ink Type	DURABrite Ultra Ink
