- Entering and editing alphanumeric values -
When you touch an alphanumeric eld on the touch screen the following keyboard appears allowing you
to give a name or make a comment to a part program.
Explanation of display elements
Alphanumeric keyboard
ELEMENT KEY FUNCTION
1 INPUT FIELD
2 ESCAPE
3 NUMERIC
4 ALPHANUMERIC
5 ENTER
6 SPECIAL CHARACTER
7 BACK SPACE
DEL DELETE
CLR CLEAR
