ESAB CUTMASTER 80
Manual 0-5396 PARTS LIST
6-1
SECTION 6: PARTS LISTS
6.01 Introduction
A. Parts List Breakdown
Thepartslistprovideabreakdownofallreplaceablecomponents.Thepartslistsarearrangedasfollows:
Section "6.03 Power Supply Replacement"
Section "6.04 Replacement Power Supply Parts"
Section "6.05 Options and Accessories"
Section "6.06 Replacement Parts for Hand Torch"
Section "6.07 Replacement Parts - for Machine Torches with Unshielded Leads"
Section "6.08 Replacement Shielded Machine Torch Leads Assemblies"
Section "6.09 Torch Consumable Parts (SL60)"
Section "6.10 Torch Consumable Parts (SL100)"
NOTE!
Partslistedwithoutitemnumbersarenotshown,butmaybeorderedbythecatalognum-
ber shown.
B. Returns
Ifaproductmustbereturnedforservice,contactyourdistributor.Materialsreturnedwithoutproperauthorization
will not be accepted.
6.02 Ordering Information
Orderreplacementpartsbycatalognumberandcompletedescriptionofthepartorassembly,aslistedintheparts
list for each type item. Also include the model and serial number of the power supply. Address all inquiries to your
authorized distributor.
6.03 Power Supply Replacement
Thefollowingitemsareincludedwiththereplacementpowersupply:workcable&clamp,inputpowercable,gas
pressureregulator/lter,andoperatingmanual.
Qty Description Catalog #
1 ESAB Cutmaster
®
80 400V CE Power Supply
    with400/415VAC,3Phase,50Hz,withinputpowercable  0559313304
6.04 Replacement Power Supply Parts
Qty Description Catalog #
1 Regulator 9-0115*
1 Filter Assembly Replacement Element 9-0116
1 Input Power Cord for 208 / 230 V Power Supply 8-4384
1 Input Power Cord for 400 V Power Supply 9-0218
NOTE!
*9-0115regulator,Iftheserialnumberofthepowersupplyispriorto#05078755then
kit number 9-0201 will be needed to replace not only the regulator (9-0115) but the logic
PCB as well. Another way to tell if the kit is needed is to see if the regulator has a small
diametertubecomingoutofthebottomtting.Ifthereisatransducerandwireharness
insteadofthetube,thekitisnotneeded.
