ESAB CUTMASTER 80
Manual0-5396 INSTALLATION
3-3
Art # A-07944
Hose Clamp
1/4 NPT to 1/4"
(6mm) Fitting
Regulator/Filter
Assembly
Inlet Port
Gas Supply
Hose
Optional Single - Stage Filter Installation
Installing Optional Two - Stage Air Filter Kit
Thisoptionaltwo-stageairlinelterisalsoforuseon
compressedairshopsystems.Filterremovesmoisture
and contaminants to at least 5 microns.
Connecttheairsupplyasfollows:
1. Attach the Two Stage Filter bracket to the back
of the power supply per instructions supplied with
thelterassembly.
NOTE!
Forasecureseal,applythread
sealanttothettingthreadsaccord-
ing to manufacturer's instructions.
DoNotuseTeontapeasathread
sealer as small particles of the tape
may break off and block the small air
passages in the torch.
2. Connectthetwostagelteroutlethosetothe
inlet port of the Regulator / Filter Assembly.
3. Usecustomer-suppliedttingstoconnecttheair
linetotheFilter.A1/4NPTto1/4"hosebarbed
ttingisshownasanexample.
Regulator
Input
Gas Supply
Hose
1/4 NPT to 1/4”
(6mm) Fitting
Regulator/Filter
Assembly
2-Stage Filter
Inlet Port (IN)
Outlet Port
(OUT)
T
wo Stage
Filter
Assembly
Art # A-07945_AC
Hose Clamp
Optional Two - Stage Filter Installation
Using High Pressure Air Cylinders
Whenusinghighpressureaircylindersastheairsupply:
1. Refer to themanufacturer’sspecications for
installation and maintenance procedures for high
pressure regulators.
2. Examinethecylindervalvestobesuretheyare
cleanandfreeofoil,greaseoranyforeignmate-
rial.Brieyopeneachcylindervalvetoblowout
any dust which may be present.
3. Thecylindermustbeequippedwithanadjust-
able high - pressure regulator capable of outlet
pressures up to 100 psi (6.9 bar) maximum and
owsofatleast300scfh(141.5lpm).
4. Connect supply hose to the cylinder.
NOTE!
Pressure should be set at 100 psi
(6.9 bar) at the high pressure cylin-
der regulator.
Supply hose must be at least 1/4
inch (6 mm) I.D.
Forasecureseal,applythread
sealanttothettingthreads,accord-
ing to manufacturer's instructions.
DoNotuseTeontapeasathread
sealer,assmallparticlesofthetape
may break off and block the small
air passages in the torch.
