ESAB ESD 7.5 - SPARE PARTS - ESD 7.5 Mechanical Parts List - Drive Section

APPENDIX
0463 751 001
- 46 -
© ESAB AB 2023
SPARE PARTS - ESD 7.5 Mechanical parts list -
Drive section
Item Qty Ordering no. Denomination Notes
1 1 0909 229 001 Base frame 200×200×12.5 L=2200
2 2 0909 248 880 Roller stand
3 4 0909 297 001 Side plate
4 4 0909 173 001 Slide bearing with flange
5 6 0909 392 001 Shaft kidney
6 2 0909 299 001 Idler shaft
7 2 0215 701 321 Key, wheel 12×8×32
8 4 0909 249 001 PU wheel 247×50
9 8 0909 302 001 Flange bearing
10 4 0909 037 001 Side support
11.a 1 0909 239 007 Gearmotor left 0.25 kW
11.b 1 0909 239 008 Gearmotor right 0.25 kW
12 2 0909 322 001 Torque stop Valid for serial no. LX130-xxxx-xxxx
13 2 0909 241 001 Cover Valid for serial no. LX130-xxxx-xxxx
13.2 1 0909 296 880 Bracket cover Valid for serial no. LX130-xxxx-xxxx,
Notshowninillustration
14 2 0909 298 001 Drive shaft
15 2 0215 701 278 Key, gearmotor 8×7×90
16 2 0215 701 321 Key, wheel 12×8×32
17 1 0909 104 001 Bracket
18 1 0909 242 001 Bracket
19 2 0909 290 001 Cover end Valid for serial no. LX130-xxxx-xxxx
