ESAB ESD 7.5 - SPARE PARTS - Control Cabinet

APPENDIX
0463 751 001
- 64 -
© ESAB AB 2023
SPARE PARTS - Control cabinet
Item Qty Ordering no. Denomination Marking Notes
1 1 0908 800 209 Circuit breaker A2 3P 10A C
2 2 0805 586 002 Contactor A7.5 and A7.6 24 VDC
3 1 0908 800 400 Power supply DC A4 24VDC/5A,
3AC400
4 1 0451 385 108 Safety relay, SSR10 A24 24 VDC
5 1 0908 800 202 Circuit breaker A3 1P 4A C
6
1 0909 552 885 CPU and software ESD 7.5 A10
1 0909 505 885 CPU and software ESD15 A10
1 0909 506 885 CPU and software ESD30 A10
1 0909 507 885 CPU and software ESD60 A10
1 0909 508 885 CPU and software ESD90 A10
1 0909 509 885 CPU and software ESD120 A10
7
1 0909 552 886 Inverter w. configuration ESD 7.5 A5 1.1 kW
1 0909 505 886 Inverter w. configuration ESD15 A5 0.55 kW
1 0909 506 886 Inverter w. configuration ESD30 A5 0.75 kW
1 0909 507 886 Inverter w. configuration ESD60 A5 1.1 kW
1 0909 508 886 Inverter w. configuration ESD90 A5 1.5 kW
1 0909 509 886 Inverter w. configuration ESD120 A5 2.2 kW
8
2 0908 800 304 Motor circuit breaker, ESD 7.5 A6.1 and A6.2
2 0908 800 302 Motor circuit breaker, ESD15 A6.1 and A6.2 0.7-1.0 A
2 0908 800 303 Motor circuit breaker, ESD30 A6.1 and A6.2 0.9-1.25 A
2 0908 800 304 Motor circuit breaker, ESD60 A6.1 and A6.2 1.1-1.6 A
2 0908 800 306 Motor circuit breaker, ESD90 A6.1 and A6.2 1.8-2.5 A
2 0908 800 307 Motor circuit breaker, ESD120 A6.1 and A6.2 2.2-3.2 A
9 4 0452 116 008 Socket A8.1, A8.2,
A8.3, A8.4
10 4 0452 116004 Relay A8.1, A8.2,
A8.3, A8.4
5A/250A AC
5A/30V DC
11 1 0802 524 553 ProfiNet A20 ET200SP
12 4 0802 524 556 Back plane module A21 – A23 ET200SP
13 2 0802 524 562 Digital input module A21.1 and
A21.2
ET200SP
14 1 0802 524 575 DO 16X24VDC A22 ET200SP
15 1 0802 524 589 AQ 2xU A23 ET200SP
16 3 0802 083 005 Terminals X1 L1, L2, L3
17 2 0805 586 002 Motor contactor, rollers A7.1 and A7.2 24 VDC
18 2 0805 586 002 Motor Contactor, rail car (opt.) A7.3 and A7.4 24 VDC
19 1 0193 129 001 Earthing bar
