ESAB ESD 7.5 - SPARE PARTS - ESD 90 Mechanical Parts List - Drive Section

APPENDIX
0463 751 001
- 58 -
© ESAB AB 2023
SPARE PARTS - ESD90 Mechanical parts list -
Drive section
Item Qty Ordering no. Denomination Notes
1 1 0909 387 001 Base frame 500×200×16 L=3650
2 2 0909 204 880 Roller stand
3 4 0909 205 001 Side plate
4 4 0909 173 021 Slide bearing with flange
5 6 0909 388 001 Shaft kidney
6 4 0909 206 001 Idler shaft
7 2 0215 701 430 Key, wheel 22×14×140
8 4 0909 096 001 PU wheel 580×180
9.a 6 0909 210 880 Flange bearing
9.b 2 0909 210 881 Flange bearing
10 4 0909 098 001 Side support
11.a
1 0909 060 001 Gearmotor left 1.00 kW, Validforserialno.015-xxx-xxxx
1 0909 364 001 Gearmotor left v2 1.00 kW,
Validforserialno.LX130-xxxx-xxxx
11.b
1 0909 060 002 Gearmotor right 1.00 kW, Validforserialno.015-xxx-xxxx
1 0909 364 002 Gearmotor right v2 1.00 kW,
Validforserialno.LX130-xxxx-xxxx
12
2 0909 209 001 Torque stop Validforserialno.015-xxx-xxxx
2 0909 379 001 Torque stop v2 Valid for serial no. LX130-xxxx-xxxx
13
2 0909 087 001 Cover Validforserialno.015-xxx-xxxx
2 0909 377 001 Cover v2 Valid for serial no. LX130-xxxx-xxxx
13.2 2 0909 296 880 Bracket cover Valid for serial no. LX130-xxxx-xxxx,
Notshowninillustration
14 2 0909 208 001 Drive shaft
15 2 0215 701 428 Key, gearmotor 20×12×160
16 2 0215 701 430 Key, wheel 22×14×140
17 1 0909 104 001 Bracket
18 1 0909 118 001 Bracket
19
2 0909 294 001 Cover end Validforserialno.015-xxx-xxxx
2 0909 380 001 Cover end v2 Valid for serial no. LX130-xxxx-xxxx
