ESAB ESD 7.5 - SPARE PARTS - ESD 30 Mechanical Parts List - Drive Section

APPENDIX
0463 751 001
- 52 -
© ESAB AB 2023
SPARE PARTS - ESD30 Mechanical parts list -
Drive section
Item Qty Ordering no. Denomination Notes
1 1 0909 035 001 Base frame 400×200×12.5 L=2790
2 2 0909 134 880 Roller stand
3 4 0909 135 001 Side plate
4 4 0909 173 014 Slide bearing with flange
5 6 0909 386 001 Shaft kidney
6 2 0909 132 001 Idler shaft
7 2 0215 701 420 Key, wheel 20×12×70
8 4 0909 076 001 PU wheel 400x90
9 8 0909 136 001 Flange bearing
10 4 0909 037 001 Side support
11.a
1 0909 058 001 Gearmotor left 0.37 kW, Validforserialno.015-xxx-xxxx
1 0909 362 001 Gearmotor left v2 0.37 kW, Valid for serial no.
LX130-xxxx-xxxx
11.b
1 0909 058 002 Gearmotor right 0.37 kW, Validforserialno.015-xxx-xxxx
1 0909 362 002 Gearmotor right v2 0.37 kW, Valid for serial no.
LX130-xxxx-xxxx
12
2 0909 138 001 Torque stop Validforserialno.015-xxx-xxxx
2 0909 366 001 Torque stop v2 Valid for serial no. LX130-xxxx-xxxx
13
2 0909 042 001 Cover Validforserialno.015-xxx-xxxx
2 0909 358 001 Cover v2 Valid for serial no. LX130-xxxx-xxxx
13.2 2 0909 296 880 Bracket cover Valid for serial no. LX130-xxxx-xxxx,
Notshowninillustration
14 2 0909 133 001 Drive shaft
15 2 0215 701 347 Key, gearmotor 14x9x125
16 2 0215 701 420 Key, wheel 20x12x70
17 1 0909 104 001 Bracket
18 1 0909 117 001 Bracket
19
2 0909 292 001 Cover end Validforserialno.015-xxx-xxxx
2 0909 367 001 Cover end v2 Valid for serial no. LX130-xxxx-xxxx
