SPARE PARTS - ESD 60 Mechanical parts list -
Drive section
Item Qty Ordering no. Denomination Notes
1 1 0909 387 001 Base frame 500×200×16 L=3650
2 2 0909 171 880 Roller stand
3 4 0909 172 001 Side plate
4 4 0909 173 021 Slide bearing with flange
5 6 0909 389 001 Shaft kidney
6 2 0909 174 001 Idler shaft
7 2 0215 701 431 Key, wheel 22×14×160
8 4 0909 057 001 PU wheel 400×90
9 8 0909 137 001 Flange bearing
10 4 0909 098 001 Side support
11.a
1 0909 095 003 Gearmotor left 0.75 kW, Validforserialno.015-xxx-xxxx
1 0909 363 003 Gearmotor left v2 0.75 kW, Valid for serial no.
LX130-xxxx-xxxx
11.b
1 0909 095 004 Gearmotor right 0.75 kW, Validforserialno.015-xxx-xxxx
1 0909 363 001 Gearmotor right v2 0.75 kW, Valid for serial no.
LX130-xxxx-xxxx
12
2 0909 177 001 Torque stop Validforserialno.015-xxx-xxxx
2 0909 375 001 Torque stop v2 Valid for serial no. LX130-xxxx-xxxx
13
2 0909 110 001 Cover Validforserialno.015-xxx-xxxx
2 0909 373 001 Cover v2 Valid for serial no. LX130-xxxx-xxxx
13.2 2 0909 296 880 Bracket cover Valid for serial no. LX130-xxxx-xxxx,
Notshowninillustration
14 2 0909 176 001 Drive shaft
15 2 0215 701 412 Key, gearmotor 18x11x160
16 2 0215 701 431 Key, wheel 22x14x160
17 1 0909 104 001 Bracket
18 1 0909 118 001 Bracket
19
2 0909 293 001 Cover end Validforserialno.015-xxx-xxxx
2 0909 376 001 Cover end v2 Valid for serial no. LX130-xxxx-xxxx
