ESAB ESD 7.5 - SPARE PARTS - ESD 120 Mechanical Parts List - Drive Section

APPENDIX
0463 751 001
- 61 -
© ESAB AB 2023
SPARE PARTS - ESD120 Mechanical parts list -
Drive section
Item Qty Ordering no. Denomination Notes
1 1 0909 387 001 Base frame 500×200×16 L=3650
2 2 0909 219 880 Roller stand
3 4 0909 220 001 Side plate
4 4 0909 173 025 Slide bearing with flange
5 3 0909 391 001 Shaft kidney
6 2 0909 221 001 Idler shaft
7 2 0215 701 448 Key, wheel 28×16×140
8 4 0909 101 001 PU wheel 580×180
9.a 6 0909 211 880 Flange bearing
9.b 2 0909 211 881 Flange bearing
10 4 0909 098 001 Side support
11.a
1 0909 105 001 Gearmotor left 1.50 kW, Validforserialno.015-xxx-xxxx
1 0909 365 001 Gearmotor left v2 1.50 kW,
Validforserialno.LX130-xxxx-xxxx
11.b
1 0909 105 002 Gearmotor right 1.50 kW, Validforserialno.015-xxx-xxxx
1 0909 365 002 Gearmotor right v2 1.50 kW,
Validforserialno.LX130-xxxx-xxxx
12
2 0909 224 001 Torque stop Validforserialno.015-xxx-xxxx
2 0909 383 001 Torque stop v2 Valid for serial no. LX130-xxxx-xxxx
13
2 0909 115 001 Cover Validforserialno.015-xxx-xxxx
2 0909 381 001 Cover v2 Valid for serial no. LX130-xxxx-xxxx
13.2 2 0909 296 880 Bracket cover v2 Valid for serial no. LX130-xxxx-xxxx,
Notshowninillustration
14 2 0909 223 001 Drive shaft
15 2 0215 701 441 Key, gearmotor 25×14×200
16 2 0215 701 448 Key, wheel 28×16×140
17 1 0909 104 001 Bracket
18 1 0909 118 001 Bracket
19
1 0909 295 001 Cover end Validforserialno.015-xxx-xxxx
1 0909 384 001 Cover end v2 Valid for serial no. LX130-xxxx-xxxx
