ESAB ESD 7.5 - SPARE PARTS - ESD 15 Mechanical Parts List - Drive Section

APPENDIX
0463 751 001
- 49 -
© ESAB AB 2023
SPARE PARTS - ESD15 Mechanical parts list -
Drive section
Item Qty Ordering no. Denomination Notes
1 1 0909 043 001 Base frame 300×200×12.5 L=2790
2 2 0909 159 880 Roller stand
3 4 0909 160 001 Side plate
4 4 0909 173 005 Slide bearing with flange
5 6 0909 390 001 Shaft kidney
6 2 0909 163 001 Idler shaft
7 2 0215 701 341 Key, wheel 14×9×63
8 4 0909 164 001 PU wheel 300×90
9 8 0909 162 001 Flange bearing
10 4 0909 037 001 Side support
11.a
1 0909 080 003 Gearmotor left 0.18 kW, Validforserialno.015-xxx-xxxx
1 0909 361 003 Gearmotor left v2 0.18 kW, Valid for serial no.
LX130-xxxx-xxxx
11.b
1 0909 080 004 Gearmotor right 0.18 kW, Validforserialno.015-xxx-xxxx
1 0909 361 004 Gearmotor right v2 0.18 kW, Valid for serial no.
LX130-xxxx-xxxx
12
2 0909 167 001 Torque stop Validforserialno.015-xxx-xxxx
2 0909 371 001 Torque stop v2 Valid for serial no. LX130-xxxx-xxxx
13
2 0909 073 001 Cover Validforserialno.015-xxx-xxxx
2 0909 368 001 Cover v2 Valid for serial no. LX130-xxxx-xxxx
13.2 2 0909 296 880 Bracket cover v2 Valid for serial no. LX130-xxxx-xxxx,
Notshowninillustration
14 2 0909 166 001 Drive shaft
15 2 0215 701 332 Key, gearmotor 12×8×110
16 2 0215 701 341 Key, wheel 14×9×63
17 1 0909 104 001 Bracket
18 1 0909 116 001 Bracket
19
2 0909 291 001 Cover end Validforserialno.015-xxx-xxxx
2 0909 372 001 Cover end v2 Valid for serial no. LX130-xxxx-xxxx
