ESAB fabricator 141i Service Manual

ESAB FABRICATOR 141i
Manual 0-5448 8-1 ASSEMBLY PROCEDURES
8.01 Installing Base panel
1. Main PCB1 assembly.
2. Heatsink on Main PCB1 assembly.
3. Install the feet of Main PCB1 assembly.
4. Install Rectifiers (torque 15 kgfcm).
5. Install Inductor.
6. Install Main PCB1 assembly screws.
7. Install Central Panel Screws.
8. Install Wire Feeder Screws.
Art # A-12089
4
3
2
1
8
5
7
6
SECTION 8:
ASSEMBLY PROCEDURES
