ESAB FABRICATOR 141i
ASSEMBLY PROCEDURES 8-6 Manual 0-5448
8.05 Installing Case
1. Install Case.
2. Install Ground Screw, which connects the ground wire to the cover.
3. Install Screws. Tighten screws.
Install Screws
Tighten Screws
Front & Rear
1
Art # A-12092
2
