36
Step 4: Wearing the fabric gloves supplied with your fascia kit, hang the Outer Fascia from the
Bevelled Outer Fascia Bracket attached to the top lid as shown.
Step 5: Check that the Outer Fascia is centred on the chassis. Screw the Outer Fascia to the
chassis at the bottom left and right of the Outer Fascia as shown.
Step 6: Attach the two inner fascia brackets as shown.
Step 7: Hang the Inner Fascia from the metal bracket on the front of the firebox. Centre the
Inner Fascia relative to the Outer Fascia.
Step 8: Screw the Inner Fascia to the bottom left and right of the firebox as shown.
