F4 Fitting the Inset Fascia Panels
Step 1: Ensure the glass and all glass retainers are
securely fitted. NOTE: If the glass gasket requires a
replacement, call your nearest Escea agent who will
ensure the part is replaced with the correct type. In the
event that the glass is broken by impact, purchase the
replacement from an authorised Escea agent only.
Step 2: Attach the Inset Outer Fascia Bracket to
the top lid as shown below. Note: Ensure the correct
orientation of the bracket. If the bracket is installed
upside down, the fascia will not fit.
Step 3: Fit the Inset Outer Fascia brackets to the
bottom left and right sides of the appliance as shown
below.
